PM2 NET began by assessing the company’s existing network infrastructure, including its Cisco wireless LAN controllers. The client’s main goals were to improve security, increase control, and deploy a solution that could scale across its locations.

PM2 NET recommended Cisco Identity Services Engine, commonly known as Cisco ISE, as the foundation for the company’s secure access strategy.

Design and Discovery

PM2 NET conducted a design session to understand the company’s existing infrastructure, network systems, access requirements, and security goals. The engineering team reviewed how Cisco ISE could be integrated into the current environment without disrupting business operations.

After completing a walkthrough of the environment, PM2 NET proposed deploying two Cisco ISE nodes for high availability. This design helped ensure continued operation if one node failed.

The proposed Cisco ISE deployment incorporated three key personas:

• Administration

• Monitoring

• Policy

This structure provided centralized control, visibility, and policy enforcement for both wired and wireless access.

Monitoring Mode and Traffic Analysis

PM2 NET first deployed Cisco ISE in monitoring mode. This allowed the team to observe incoming network traffic and better understand user behavior, device types, authentication patterns, and access requirements.

This monitoring phase was critical because it gave PM2 NET and the client’s IT team the information needed to tune policies before enforcement. By analyzing the traffic, PM2 NET could determine which devices belonged to employees, guests, contractors, printers, scanners, and other endpoint categories.

Network Segmentation and Policy Tuning

After gaining visibility into the environment, PM2 NET moved into a tuning period. During this phase, the team prepared the environment for segmentation and policy enforcement.

One of the key recommendations was to separate network access based on user and device type. For example, guest users would be placed on a guest VLAN with internet-only access and no access to enterprise databases or internal systems.

This segmentation helped reduce risk by ensuring that users and devices only received the level of access required for their role.

Enforcement Mode

Once the policies were tuned, PM2 NET configured Cisco ISE in enforcement mode. This allowed the company to actively enforce network access policies, including guest credentials, guest SSID access, device classification, and user-based authorization.

PM2 NET configured four SSIDs to support different access requirements:

• Corporate users: Full network access to internal resources

• Guests: Internet access only, with no internal resource access

• Devices: Access for agentless devices such as scanners and printers that do not support 802.1X

• Contractors: Internet access and limited access to approved internal resources, such as printers and scanners

This model allowed the company to support multiple access scenarios without exposing sensitive internal systems to unnecessary risk.

Wired Device Security

PM2 NET also addressed wired network security. The company needed protection not only for wireless users but also for individuals or devices connecting through switches.

Cisco ISE supported this requirement through TACACS+, helping manage authentication, authorization, and accounting for wired network devices. This gave the IT team greater control over administrative access and improved accountability across the wired infrastructure.

The Result

PM2 NET helped the company deploy a robust network access control solution that improved endpoint security, user visibility, network segmentation, and BYOD control.

With Cisco ISE, the company gained the ability to identify who was connecting to the network, what device they were using, where they were connecting from, and what level of access they should receive.

The solution also helped the company scale its security approach across multiple locations while simplifying management through centralized visibility and policy control.

Key Advantages

Secure BYOD Enablement

The company could now support BYOD for employees, guests, and authorized contractors in a more secure way. Employees could access internal resources through proper authentication, while guests were restricted to internet-only access.

This allowed the business to gain the productivity and flexibility benefits of BYOD while reducing exposure to internal systems.

Identity-Based Network Access

Cisco ISE allowed the company’s IT staff to track and trace user identities across the network. Users connecting to WiFi with credentials could be authenticated and assigned the correct level of access.

Employees using 802.1X authentication could securely access internal resources, while guests and contractors were placed into restricted access groups.

Device Profiling

Cisco ISE also enabled profiling for devices that did not support 802.1X authentication, such as printers and scanners. These devices could be identified and authorized through Media Access Control address bypass, also known as MAB.

This helped the company manage agentless devices without weakening the overall security model.

Improved Wired and Wireless Visibility

The Cisco ISE management console gave the IT team visibility into both wired and wireless devices. Network administrators could see who logged in, where they connected from, what type of device they used, which operating system was running, and other important endpoint details.

This visibility made it easier to detect suspicious activity, assess endpoint risk, and manage access across the environment.

Stronger Endpoint Compliance

The solution supported endpoint compliance by helping the company identify and manage devices connecting to the network. Cisco ISE provided a framework for policy-based access and helped the organization reduce the risks associated with unmanaged or noncompliant endpoints.

Scalable Multi-Location Security

Because the company operated across multiple warehouses and corporate offices, scalability was essential. Cisco ISE gave the organization a centralized and expandable security model that could support its growing operational footprint.

Key Outcomes

• Assessed the company’s existing Cisco wireless infrastructure

• Designed and deployed Cisco ISE with two nodes for high availability

• Implemented monitoring, tuning, and enforcement phases

• Created segmented access for employees, guests, devices, and contractors

• Improved BYOD security across wired and wireless networks

• Enabled endpoint profiling for printers, scanners, and agentless devices

• Strengthened network visibility and access control across multiple locations

• Supported scalable security management for corporate offices and warehouses
